354 9 Programming: Subprograms and Program Section Repeats
9.6 Programming Examples
10 L Z+250 R0 F MAX M6 Tool change
11 TOOL CALL 2 Z S4000 Call the drilling tool
12 FN 0: Q201 = -25 New depth for drilling
13 FN 0: Q202 = +5 New plunging depth for drilling
14 CALL LBL 1 Call subprogram 1 for the entire hole pattern
15 L Z+250 R0 F MAX M6 Tool change
16 TOOL CALL 3 Z S500 Tool call: reamer
17 CYCL DEF 201 REAMING Cycle definition: REAMING
Q200=2; SET-UP CLEARANCE
Q201=-15; DEPTH
Q206=250; FEED RATE FOR PLNGNG
Q211=0.5; DWELL TIME AT DEPTH
Q208=400; RETRACTION FEED RATE
Q203=+0; SURFACE COORDINATE
Q204=10; 2ND SET-UP CLEARANCE
18 CALL LBL 1 Call subprogram 1 for the entire hole pattern
19 L Z+250 R0 F MAX M2 End of main program
20 LBL 1 Beginning of subprogram 1: Entire hole pattern
21 L X+15 Y+10 R0 F MAX M3 Move to starting point for group 1
22 CALL LBL 2 Call subprogram 2 for the group
23 L X+45 Y+60 R0 F MAX Move to starting point for group 2
24 CALL LBL 2 Call subprogram 2 for the group
25 L X+75 Y+10 R0 F MAX Move to starting point for group 3
26 CALL LBL 2 Call subprogram 2 for the group
27 LBL 0 End of subprogram 1
28 LBL 2 Beginning of subprogram 2: Group of holes
29 CYCL CALL 1st hole with active fixed cycle
30 L IX+20 R0 F MAX M99 Move to 2nd hole, call cycle
31 L IY+20 R0 F MAX M99 Move to 3rd hole, call cycle
32 L IX-20 R0 F MAX M99 Move to 4th hole, call cycle
33 LBL 0 End of subprogram 2
34 END PGM UP2 MM
