PX4i and PX6i High Performance Printer User Guide 117
Non-Adhesive Strip
Self-Adhesive Strip
External Media Width Including Liner (a)
Liner (b)
The liner must not extend more than a total of 1.6 mm (0.06 in) outside the face
material and should protrude equally on both sides.
External Media Width Excluding Liner (c)
a
Non-Adhesive
Strip
Printer Measurement Value
PX4i Maximum 120 mm (4.72 in)
Minimum 25.0 mm (1.00 in)
PX6i Maximum 170 mm (6.69 in)
Minimum 76.0 mm (3.00 in)
Printer Measurement Value
PX4i Maximum 118.4 mm (4.66 in)
Minimum 23.8 mm (0.94 in)
PX6i Maximum 168.4 mm (6.63 in)
Minimum 74.4 mm (2.93 in)
