36 PX4i and PX6i High Performance Printer User Guide
17. Press to advance the media and adjust the media feed.
Loading Media for Printing From an External Supply
You can place the media supply, such as fanfold tickets or tags, behind the printer.
The external supply can be used with these printing methods:
• Tear-off (straight-through)
• Cut-off
• Peel-off (upper slot only)
• Internal batch takeup
It is strongly recommended using the fanfold guide accessory. This guide makes
loading media easier and accurately guides the media. The fanfold guide can be
adjusted for various media widths down to 40 mm (1.57 in).
Note: Make sure to protect the media from dust, dirt, or other foreign particles that can
impair the printout quality or cause unnecessary wear to the printhead.
