PX4i and PX6i High Performance Printer User Guide 73
Use the following table to understand SNMP settings.
Configuring TCP/IP Settings
Use the TCP/IP settings page to view and change TCP/IP network settings.
To configure TCP/IP settings
1. Click Network Admin > TCP/IP.
2. View or update your settings.
3. Click Submit TCP/IP settings.
Setting Description
Read Community Community with rights to read the SNMP MIBs.
Read/Write Community Community with rights to read and write SNMP MIBs.
Username Username when using SNMPv3. The default value is “initial”.
Authentication Key The authentication key for SNMPv3. The default value is “auth_key”.
Encryption Key The privacy key for SNMPv3. The default value is “priv_key”.
System Name Administrative name for the SNMP node.
Authentication Failure
Trap
Defines if a trap is sent when an unauthorized SNMP request tries to
access the printer. Choose Enable to send the trap.
Trap Address Settings Click Add to specify these trap address settings:
• Trap Address: IP address of the receiver of SNMP traps. You can
specify up to four trap addresses.
• Trap Port: The port where SNMP traps are sent. The default port if
162.
• Trap Community: Defines the community to which SNMP traps will
be sent.
• Friendly Name: A user-defined text string that identifies the trap.
• Trap Enable Status: Defines whether the specified trap is enabled.
