Honeywell PX940 User Manual

50 PX940 User Guide
Reporting and Statistics
In the Webpage > Verification> Verification Results you can see the list of the
individual reports (if available).
You can also see the number of labels verified, failure rates, and print statistics.
Report Formats
Individual Report
For individual report, it saves the detailed information of the barcodes in the label.
The content includes barcode type, size, encoded data, ANSI grade and the
detailed parameter of ANSI grade. Each individual label report consists of 3 parts.
• Report header
•Barcode information
• Barcode grading parameter (not applicable for Read/No Read verification type)
• 1D Barcode 10 line profile grading parameter (not applicable for Read/No Read
verification type)
Summary Description
File Format xml
File Name Individual report:
<Printer Model Name>_<Printer Serial Number>_<Label
ID>_<YYYYMMDD>_<HHMMSS>.xml
Example: PX940V_0000001234567_1_20181026_142800.xml
Summary report:
<Printer Model Name>_<Printer Serial Number>_<Start of Label ID>_<End of
Label ID>.xml
Example: PX940V_0000001234567_1_50.xml
Content The various measured parameters for all verified barcodes found in the
label

Honeywell PX940 Specifications

General

Ethernet LAN	Yes
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Flash memory	256 MB
Internal memory	1024 MB
Page description languages	DP, DPL, XML, ZPL II, IPL
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Cables included	AC
Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Minimum print length	4800 mm
Maximum printing width	108 mm
Ribbon width	110 mm
Core diameter	25 mm
Ribbon length	450 m
Maximum roll diameter	80 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Display	LCD
Product color	Black
Display diagonal	3.5 \
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	506 mm
Width	261 mm
Height	398.7 mm
Weight	23000 g
