8.4 Configuring the Environment Monitoring Parameters of
the ETP4890
This topic describes how to configure the environment monitoring parameters of the ETP4890
through the CLI.
Mapping Between Monitoring Parameters and Device Ports
Table 8-13 describes the mapping between the monitoring parameters displayed on the sensor
transfer box.
Table 8-13 Mapping between the monitoring parameters displayed on the host and the ports on
the sensor transfer box
Monitoring
Parameter
Displayed
on the Host
Device
Port
Application in
the F01D200
Cabinet
Application in
the F01D500
Cabinet
Application in
the F01D1000
Cabinet
Digital 0 JTD1 Fan monitoring
board of the
HABD shelf
Fan monitoring
board of the
HABD shelf
Fan monitoring
board of the
HABD shelf
Digital 1 JTD2 Not connected by
default, used to
add a user-defined
monitoring digital
parameter
Fan monitoring
board of the HABF
shelf
Fan monitoring
board of the HABF
shelf
Digital 2 JTD3 Not connected by
default, used to
add a user-defined
monitoring digital
parameter
Not connected by
default, used to
add a user-defined
monitoring digital
parameter
Fan monitoring
board of the
HABD shelf in the
right device
compartment
Digital 3 JTD4 surge protector surge protector surge protector
Digital 4 SMOKE Smoke sensor Smoke sensor Smoke sensor
Digital 5 JTD6 Heat exchanger Heat exchanger Heat exchanger
Digital 6 JTD7 Door status sensor
of the MDF
compartment
Door status sensor
of the MDF
compartment
Door status sensor
of the MDF
compartment
Door alarm JTM1 Door status
sensors of the
device
compartment and
heat exchanger
compartment
Door status
sensors of the
device
compartment and
heat exchanger
compartment
Door status
sensors of the
device
compartment and
heat exchanger
compartment
UA5000 Universal Access Unit
Environment Monitoring 8 ETP4890 Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
138
