Monitoring
Parameter
Displayed on
the Host
Device Port Application in the
F02AF Cabinet
(Configured with the C-
Type PDU)
Application in the F02AF
Cabinet (Configured
with the H-Type PDU)
Digital 17 Reserved Unavailable Unavailable
Digital 18 Reserved Unavailable Unavailable
Digital 19 Reserved Unavailable Unavailable
Digital 20 Reserved Unavailable Unavailable
Digital 21 Reserved Unavailable Unavailable
Digital 22 Reserved Unavailable Unavailable
NOTE
Before adding a user-defined analog or monitoring digital parameter, make sure that the port corresponding
to this parameter is connected with an environment monitoring cable.
Data Plan
NOTE
l The preceding data is configured according to the actual requirements. When the actually planned value
of a parameter is the same as the default value, it is not necessary to configure the parameter.
l The configuration of the monitoring parameters in the F02AF cabinet configured with the C-type PDU
is basically the same as that in the F02AF cabinet configured with the H-type PDU. The only difference
lies in the definition of the PDU monitoring parameter, but the valid levels for these two PDUs are
both set to low level.
Table 4-10 provides the data plan for configuring the H304ESC board. In this topic, the
application in the F02AF cabinet with the C-type PDU is considered as an example.
Table 4-10 Data plan for configuring the H304ESC board
Item
Data Remarks
EMU Type: H304ESC H304ESC is displayed as H304ESC on the
CLI.
SN: 0 -
Subnode ID: 30 The serial port of the H304ESC is an RS-232
serial port, and the subnode ID must be set to
30.
Analog
parameters
Analog parameter ID: 0 This analog parameter is set according to the
actual requirements. The built-in analog
parameter is set here to monitor the ambient
temperature of the device.
UA5000 Universal Access Unit
Environment Monitoring 4 H304ESC Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
36
