4.3 Configuring the Environment Monitoring Parameters of
the H304ESC Board
This topic describes how to configure the environment monitoring parameters of the H304ESC
board through the CLI.
Mapping Between Monitoring Parameters and Device Ports
Table 4-9 describes the mapping between the monitoring parameters displayed on the host and
the ports on the H304ESC.
Table 4-9 Mapping between the monitoring parameters displayed on the host and the ports on
the H304ESC
Monitoring
Parameter
Displayed on
the Host
Device Port Application in the
F02AF Cabinet
(Configured with the C-
Type PDU)
Application in the F02AF
Cabinet (Configured
with the H-Type PDU)
Analog 0 Temperature Temperature Temperature
Analog 1 Reserved Unavailable Unavailable
Analog 2 Reserved Unavailable Unavailable
Analog 3 Reserved Unavailable Unavailable
Analog 4 Power
supply
voltage
Power supply voltage Power supply voltage
Analog 5 JTA1 Not connected by default,
used to add a user-defined
monitoring analog
parameter
Not connected by default,
used to add a user-defined
monitoring analog
parameter
Analog 6 JTA2 Not connected by default,
used to add a user-defined
monitoring analog
parameter
Not connected by default,
used to add a user-defined
monitoring analog
parameter
Analog 7 JTA3 Not connected by default,
used to add a user-defined
monitoring analog
parameter
Not connected by default,
used to add a user-defined
monitoring analog
parameter
Digital 0 JTP1 (MDF) Not connected by default,
used to add a user-defined
monitoring digital
parameter
Not connected by default,
used to add a user-defined
monitoring digital
parameter
Digital 1 JTM1 (door
status)
Door status sensor Door status sensor
UA5000 Universal Access Unit
Environment Monitoring 4 H304ESC Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
34
