Figure 10-2 Appearance of the door status sensor
Technical Specifications
Table 10-3 describes the technical specifications of the door status sensor.
Table 10-3 Technical specifications of the door status sensor
Parameter Value
Power supply voltage 12 V DC
Switch status On
Node capacity
Bearable voltage: 150 V DC
Bearable current: 0.5 A
Impedance 0.3 ohm
Output signal type Dry contact
10.1.4 Smoke Sensor
The smoke sensor is used to detect the smoke generated by the fire to prompt the fire in advance.
Appearance
The smoke sensor is sensitive to the white smoke that is generated in burning. The smoke sensor
can prompt the fire in advance.
Figure 10-3 shows the smoke sensor.
UA5000 Universal Access Unit
Environment Monitoring 10 Sensors
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
172
