Huawei UA5000 User Manual

Table 5-3 Settings of SW1
Electrical
Switch
Setting Indication Factory Default
SW1-1 to
SW1-4
Supported Used to set the address of the
environment monitoring board.
SW1-1: ON
SW1-2: ON
SW1-3: OFF
SW1-4: OFF
SW1-5 Not
supported
- ON
SW1-6 ON The rate of the serial port is 19200
bit/s.
OFF
OFF The rate of the serial port is 9600 bit/
s.
SW1-7 ON The external sensor of JTA1 is of the
current type.
ON
OFF The external sensor of JTA1 is of the
voltage type.
SW1-8 ON The external sensor of JTA2 is of the
current type.
ON
OFF The external sensor of JTA2 is of the
voltage type.
When the ESCM EMU adopts the RS-485 communication mode, SW1-1 to SW1-4 are used to
set the address of the environment monitoring board. Table 5-4 shows the settings of SW1-1 to
SW1-4.
Table 5-4 Settings of SW1-1 to SW1-4
SW1-4
SW1-3 SW1-2 SW1-1 Address Value
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
0 0 1 1 3
0 1 0 0 4
0 1 0 1 5
0 1 1 0 6
0 1 1 1 7
UA5000 Universal Access Unit
Environment Monitoring 5 ESCM Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
49
