Huawei UA5000 User Manual

Table 9-6 Default settings of DIP switches of SW201
DIP Switch Meaning Default Setting
SW201-1 By default, set the terminal to corresponde
to serial port 0 (mapping J201).
ON
SW201-2 ON
SW201-3 By default, set the terminal to corresponde
to serial port 1 (mapping J202).
ON
SW201-4 ON
Table 9-7 and Table 9-8 describe the settings of DIP switches of SW201.
Table 9-7 Settings of SW201-1 and SW201-2
SW201-2 SW201-1 Terminal Matching Serial Port 0
ON ON Yes
OFF OFF No
Table 9-8 Settings of SW201-3 and SW201-4
SW201-4
SW201-3 Terminal Matching Serial Port 1
ON ON Yes
OFF OFF No
9.4 LED
The LED on the front panel of the fan tray indicates the running status of the fans. This topic
describes the status and meanings of the LED.
The LED is on the right of the fan tray. Table 9-9 describes the LED of the fan tray.
Table 9-9 LED of the fan tray
LED
Status Description
STATUS Yellow: on for 0.3s and off for 0.3s
repeatedly
The fan tray is not registered or it is
being loaded.
Green: on for 1s and off for 1s
repeatedly
The fan tray works in the normal state.
Yellow: on for 1s and off for 1s
repeatedly
The fan tray generates a warning that
does not affect the services.
UA5000 Universal Access Unit
Environment Monitoring 9 Fan Tray Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
155
