Monitoring
Parameter
Displayed on the
Host
Device Port Application in the F02A Cabinet
Digital 14 JTD13 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 15 Reserved Unavailable
Digital 16 Reserved Unavailable
Digital 17 Reserved Unavailable
Digital 18 Reserved Unavailable
Digital 19 Reserved Unavailable
Digital 20 Reserved Unavailable
Digital 21 Reserved Unavailable
Digital 22 Reserved Unavailable
NOTE
Before adding a user-defined monitoring analog or digital parameter, make sure that the port corresponding
to this parameter is properly connected to an environment monitoring cable.
Data Plan
Table 3-11 provides the data plan for configuring the H303ESC board.
Table 3-11 Data plan for configuring the H303ESC board
Item
Data Remarks
EMU Type: H303ESC H303ESC is displayed as H303ESC on the
CLI.
SN: 0 -
Subnode ID: 30 The serial port of the H303ESC is an RS232
serial port, and the subnode ID must be set to
30.
Analog
parameters
Analog parameter ID: 0 This analog parameter is set according to the
actual requirements. The built-in analog
parameter is set here to monitor the ambient
temperature of the device.
Upper alarm threshold of
analog parameter 0: 50
When the ambient temperature of the device
is equal to or higher than 50°C, the host
reports an alarm.
Default: 55°C.
UA5000 Universal Access Unit
Environment Monitoring 3 H303ESC Monitoring Solution
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
17
