Silkscr
een
Function Status Definition
Green: on for 0.5s and off for
0.5s repeatedly
The heat exchanger is running
in the normal state, but its
communication with the
system is interrupted.
Green: off No power supply is provided.
Alarmin
g
Alarm LED Red: on A fault occurs.
Red: off No alarm is generated.
Specifications
Table 10-9 lists the specifications of the HX02-22SH heat exchanger.
Table 10-9 Specifications of the HX02-22SH heat exchanger
Item Specifications
Dimensions (W x D x H) 410 mm x 154 mm x 970 mm
Weight 23 kg
Heat exchange performance 80 W/K
Typical Power Consumption 100 W
10.1.10 HX03T-22SH Heat Exchanger
This topic provides the appearance of the HX03T-22SH heat exchanger, describes the functions
and working principles of it, and lists parameters of it.
Appearance
Figure 10-13 shows the appearance of the HX03T-22SH heat exchanger.
UA5000 Universal Access Unit
Environment Monitoring 10 Sensors
Issue 01 (2012-08-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
183
