264
Chapter 3 C/T PORT
C/T PORT
C/T PORT Submenus
Port Type
This item selects the desired active CTHI interface and appears only when
the CTHI option is installed.
The factory default is Twinax.
Device Address
Allows you to set the device address from 0 through 6. The host directs data
and commands on the twinax line to a specific device based on its unique
device address. After the address has been changed, a Power On Reset
(POR) status is sent to the host.
The factory default is 1.
Timeout
This item allows you to set the time that the printer, when it has not received
data from its host, will begin to service all other host ports looking for data to
print.
The range is 5-60 seconds, and the factory default is 10 seconds.
C/T PORT
1
Port Type
Twinax* Coax Disable
Timeout
10 sec.* 5-60 sec.
Report Status
Disable* Enable
Device Address
Address 1* Address 0-6
Notes:
* = Factory Default
1
Appears only if the CTHI option is installed.
