A Specifications
Print Method
Table 18. Printing Specifications
5504-R40 5504-R60 5504-R80
Print Resolution (dpi)
300 300 300
Min. Dot Size (sq. in)
.0033
(.083 mm)
.0033
(.083 mm)
.0033
(.083 mm)
Bar Code Modulus (mils)
Picket Fence
Ladder
3.3 - 110
10 - 110
3.3 - 110
10 - 110
3.3 - 110
10 - 110
Max. Print Speed (ips)
886
Max. Slew Speed (ips)
886
Max. Print Width (in.)
4.1
(104.1 mm)
6.6
(167.6 mm)
8.5
(215.9
mm)
Flash Memory (MB) Standard
888
Flash Memory (MB) Maximum
16 16 16
DRAM (MB) Standard/Max
32 32 32
Max. Print Length (in.) at max. width, std.
DRAM
(1,2)
97
(2464 mm)
62
(1575 mm)
48
(1219 mm)
Max. Print Length (in.) at max. width, std.
MB DRAM
(2)
99
(2515 mm)
99
(2515 mm)
99
(2515 mm)
NOTES:
1. These figures are approximate and depend upon the active emulation.
2. These values may not be supported at maximum throughput.
