POCKET BEEP AND TONE/DIGITAL SQUELCH
New2001
13
■ Tone/Digital code/call sign squelch operation
The tone, digital code or call sign squelch opens only when
receiving a signal with the same pre-programmed subaudible
tone, digital code or call sign, respectively.
DD
Setting from the application
qSet the desired operating frequency and mode (FM or Dig-
ital voice).
• Using the CTCSS — in FM mode
wDisplays the Set Mode screen.
- Select “Edit Set Mode(C
)...” in View menu.
- Click “” in tool bar.
- Press [F7] key on the PC keyboard.
eDouble click the “CTCSS Tone” cell, then select the desired
tone frequency.
rClick [TONE] once or twice until “TSQL” appears to turn the
tone squelch function ON.
tWhen a signal with matched tone signal is received the
squelch opens and the signal can be heard.
• When the received signal includes an unmatched tone, the
squelch does not open. However, the S/RF indicator shows the
received signal strength.
yPush [PTT] to answer.
uClick [TONE] once to cancel the tone squelch function.
•“TSQL” indication disappears.
Double click, then
select the desired
tone frequency.
