Icom ID-1 User Manual

59
8 REPEATER OPERATION— VOICE
New2001
■ Repeater tone frequency setting
DD
Setting from the application
qDisplays set mode screen by performing one of the follow-
ing operations.
- Select “Edit SetMode(C
)...” in view menu.
- Click “” button in tool bar.
- Click [SET].
- Press [F7] key on the PC keyboard.
wDouble click “Repeater Tone” frequency cell, then select
the desired frequency from the displayed list.
• To close the screen, click “” or repeat the operation as step q.
DD
Setting from the RC-24
qPush [MODE] several times to select FM mode.
wPush [TXinh• ] for 0.5 sec. to enter set mode.
ePush [MODE] or [TXinh• ] to select “Repeater
Tone” item.
rRotate [DIAL] to select the desired tone frequency.
• See the table below for the available frequencies.
tPush [PWR] momentarily to exit set mode.
• Available tone frequencies (unit: Hz)
67.0
69.3
71.9
74.4
77.0
79.7
82.5
85.4
88.5
91.5
94.8
97.4
100.0
103.5
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
159.8
162.2
165.5
167.9
171.3
173.8
177.3
179.9
183.5
186.2
189.9
192.8
196.6
199.5
203.5
206.5
210.7
218.1
225.7
229.1
233.6
241.8
250.3
254.1
LOW
Repeater Tone
88.5
[MODE]
[DIAL]
[TXinh• ]
Double click
Appears
Select from the above list.
