57
8 REPEATER OPERATION— VOICE
New2001
■ Accessing an FM repeater
DD
Setting from the application
qClick [MODE] to select FM mode.
•“FM” appears.
wSet the desired receive frequency (repeater output frequency).
eClick [RP] several times to select minus or plus duplex.
•“RP–” or “RP+” appears.
• 12 MHz is set as the default for the USA version. Refer to page
60 for offset frequency setting.
rClick [TONE] to turn the repeater tone encoder ON.
•“TONE” appears.
• 88.5 Hz is set as the default. Refer to page 59 for tone frequency
setting.
NOTE for the USA version: During the auto repeater
function ON, the steps e and r are not necessary, de-
pending on the settings. See page 106 for the auto re-
peater function.
tPush and hold [PTT] to transmit.
• The display frequency automatically changes to the transmit fre-
quency (repeater input frequency).
• If the repeater indicator, “RP–” or “RP+,” and “” blink, con-
firm that the duplex direction and the offset frequency (p. 60) is
set correctly.
yRelease [PTT] to receive.
uClick [MONI] to check whether the other station’s transmit
signal can be received directly.
iTo return to simplex operation, click [RP] several times to
clear the “RP–” or “RP+” indicator.
oTo turn OFF the repeater tone encoder, click [TONE] sev-
eral times until no tone indicators appear.
Displays transmit frequency.
Indicates transmit output power level.
Appears during transmit.
ID-1_ENG_2.qxd 04.9.22 9:29 Page 57 (1,1)
