SAFETY
Locate, read, understand and follow all Danger, Warning, Caution, and
Operating Instructions on the product and in all Manuals. Failure to
comply with safety precautions described in the manuals supplied with
the product, this manual or any of the labels and tags attached to the
product may result in death, serious injury or property damage.
Check that all labels, tags and data (name) plates are in place and legible.
•
•
It is your responsibility to make this information available to others.
If you have any questions about safety or procedures not included in
this manual, ask your supervisor or contact any Ingersoll Rand o ce or
quali ed Ingersoll Rand distributor.
•
•
TRANSPORTATION/RECEIPT/HANDLING
Transportation
Ensure machine is secured against movement during transportation.
Receipt
Before signing the delivery receipt, inspect for damage and missing parts. If
damage or missing parts are apparent, make the appropriate notation on the
delivery receipt, then sign the receipt. Immediately contact the carrier for an
inspection.
All material shall be held in the receiving location for the carrier’s inspection.
Delivery receipts that have been signed without a notation of damage or
missing parts are considered to be delivered “clear.” Subsequent claims are
then considered to be concealed damage claims. Settle damage claims
directly with the transportation company.
If you discover damage after receiving the compressor (concealed damage),
the carrier shall be noti ed within 15 days of receipt and an inspection shall
be requested by telephone with con rmation in writing. On concealed
damage claims, the burden of establishing that the compressor was
damaged in transit reverts back to the claimant.
Read the compressor nameplate to verify it is the model ordered, and read
the motor nameplate to verify it is compatible with your electrical conditions.
Make sure electrical enclosures and components are appropriate for the
installation environment.
Unpacking and Handling
The compressor will normally be delivered with a polyethylene or other
cover. If a knife has to be used to remove this cover, ensure that the exterior
paintwork of the compressor is not damaged.
Incorporated within the base of the compressor are slots to enable a fork lift
truck to move the compressor. Ensure truck forks are fully engaged on both
sides. Alternatively a special lifting frame can be used to enable a crane or
hoist to move the compressor. Use only marked lifting points.
Once the packaging and pallet are discarded and the compressor is in its
nal position, remove the yellow painted transit brackets from the resilient
mounts and store for future use or discard.
For Variable Speed and Fixed Speed (R30-37 kW)
(2) brackets from the Airend and separator tank support.
(1) bracket from the motor mounting bracket.
For Variable Speed Drive (VSD) (R37e-160 kW)
(3) brackets at the separator tank
(1) bracket from the air end discharge elbow.
(1) bracket from the air end support.
For Fixed Speed (FS) (R37e-160 kW)
(3) brackets at the separator tank
(1) bracket from the air end support.
(1) bracket from the motor mounting bracket.
Long Term Storage
If the product will not be commissioned within six months of receipt, it
should be prepared for long term storage. Please contact Ingersoll Rand for
details.
•
•
•
•
•
•
•
•
ABOUT THIS MANUAL
The purpose of this manual is to provide site planning, installation and operation guidelines for the compressor.
For supporting documentation refer to Table 1.
Table 1 : Product Manuals
Publication Product
Part/Document Number by Region
Americas EMEIA * Asia Paci c
Product Safety Information Manual All 80446313 80446156 80446321
Product Maintenance Manual All 80447170 80447196 80447212
Product Parts Information Manual
R30-37 24342156
R37-45 80448095
R55-75 80447592
R90-160 kW Single-Stage 80446057
R90-160 kW Two-Stage 80446065
* Europe, Middle East, India and Africa
Product speci cation sheets and reference drawings are also available.
