Harness Interconnection
The harness number refers to and corresponds with the annotations in the schematic drawing on the adjacent page.
Harness No. Issue Remarks Page
1 Front Console
721/10940 1 4 speed Powershift / Synchro Shuttle 151 - 1
721/10937 3 6 speed Powershift (ShiftMaster) 151 - 3
2 Side Console
721/10936 1 Machines up to S/No. 933756 153 - 1
721/10970 2 Machines from S/No. 933757 153 - 5
3 Cab Roof
721/10966 1 USA only 155 - 1
721/10965 1 Not USA 155 - 3
4 Interior Light, Radio Speakers
721/11050 1 155-5
5 Steer Controls
721/10968 1 Not crab steer 157 - 1
721/10967 1 157-2
6 Cab Link
721/10943 1 6 speed Powershift (ShiftMaster) 160 - 1
721/10942 1 4 speed Powershift / Synchro Shuttle 160 - 3
7 Transmission
721/10941 1 6 speed Powershift 160 - 5
721/10938 2 Synchro Shuttle 160 - 7
721/10939 1 4 speed Powershift 160 - 8
8 Engine/Mainframe
721/10935 2 165-1
9 Rear Lights, Hydraclamp
721/10944 1 Sideshift 165 - 3
10 Rear Horn, Alarm
721/10946 1 Sideshift 165 - 4
721/10947 1 Centre mount 165 - 5
11 Auxiliary
721/10974 1 Excavator 165 - 6
*
150 - 1
Drawings
Introduction
The following drawings are reproduced from production electrical harness drawings. Each harness drawing includes tables
showing wire connections and destinations for all the connectors on the harness.
Section C Electrics
9803/3280
Section C
150 - 1
Issue 3*
Harness Data
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
