jcb 215 Service Manual

ii
Section D Controls
9803/3280
Section D
ii
Issue 1
Contents Page No.
Precision Control (Servo) Machines from January 2003
(continued)
Servo Pressure Supply Valve
- Removal and Replacement 51 - 1
- Dismantling and Assembly 51 - 2
Control Rods and Linkages
Dismantling and Assembly
- Loader Valve Controls 60 - 1
- Excavator Valve Controls 61 - 1
Control Cables
Removal and Replacement
- Cab Heater Controls 70 - 1
- Stabiliser Controls 71 - 1
- Boom Lock Cable 72 - 1
Boom Stop Setting 72 - 1
- Engine Throttle Cable 73 - 1
- Auxiliary Footpedal Cable 74 - 1
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
