7 - 1
Section F Transmission
9803/3280
Section F
7 - 1
Issue 1
Technical Data
Engine Stall Speed Combinations
The stall speed figures on the following pages are intended as a guide to assist with machine fault diagnosis. The figures relate to
tests conducted at an ambient of 25 deg. C and barometric pressure of 100 kPa (sea level). Note that changes in ambient
temperature, pressure and humidity and fuel grade will affect engine power and hence the stall figures.
As an example, at 10,000 ft the power reduction of a naturally aspirated engine could be 29% and for a turbo engine 8%.
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
