jcb 215 Service Manual

Transmission
9803/3280 Issue 1
Front Axle - Steer Drive Type SD55, SD70
15 - 1 15 - 1
Basic Operation
Section F Section F
Component Identification
The illustration shows a typical steer drive front axle.
A Yoke connection to propshaft
B Pinion
C Crownwheel
D Differential unit
E Drive shaft
F Universal coupling
G Reduction gear hub
H Steer swivel trunnion bearings
J Axle pivot
K Oil fill and drain plugs
A355950
B
A
E
F
G
C
D
H
J
K
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
