jcb 215 Service Manual

992/04800
Flange Spanner - for locking pinion
flange while pinion nut is slackened or
torque set
4 - 12
Section 1 General Information
9803/3280
Section 1
4 - 12
Issue 1
S197040
Service Tools (cont'd)
Section F - Transmission
892/00182 Bearing Pad Driver
S216310
992/04000
Torque Multiplier (use in conjunction with a torque wrench to give a
5:1 multiplication when tightening pinion nuts)
S197030
Test Point
1 892/00964 Test point (1/8 BSP) Powershift
2 892/00965 Test point (3/8 BSP) Powershift
3 892/00966 Test point (1/4 BSP) Syncro Shuttle
S316250
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
