jcb 215 Service Manual

Contents Page No.
Steering Column
Removal and Replacement 30 - 1
Dismantling and Assembly 30 - 1
Shovel Reset (214e Machines) 31-1
Return To Dig
Operation 33 - 1
Adjustment 33 - 1
Precision Control (Servo) Machines up to serial no. 931159
Basic System Operation
- Component Location 35 - 1
- Component Identification 35 - 2
- Circuit Description 35 - 2
- Electrical Operation 35 - 4
- Hydraulic Operation 35 - 4
Electrical Connections 36 - 1
Fault Finding 37 - 1
Service Procedures
- Testing the Pilot Pressure 38 - 1
- Renewing the Pilot Supply Valve Oil Filter 38 - 1
- Pilot Hose Removal and Replacement 38 - 3
- Seat Arms Control Lever - Adjustment 38 - 4
Pilot Control Valves
- Removal and Replacement 40 - 1
- Dismantling and Assembly 40 - 3
- Electrical Switches Removal and Replacement 41 - 1
Precision Control (Servo) Machines from January 2003
Basic System Operation
- Component Location 45 - 1
- Component Identification 45 - 2
- Circuit Description 45 - 2
- Hydraulic Operation 45 - 3
- Electrical Operation
Joystick Controller 45 - 6
Pump Dump Controller (Power Management ECU) 45 - 6
- Joystick Controllers - Description 45 - 7
- Servo Pressure Supply Valve - Description 45 - 8
Fault Finding 47 - 1
Service Procedures
- Testing the Servo Pressure 48 - 1
Joystick Controllers
- Removal and Replacement 50 - 1
- Dismantling and Assembly 50 - 2
i
Section D Controls
9803/3280
Section D
i
Issue 4*
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
