1 - 1
Section F Transmission
9803/3280
Section F
1 - 1
Issue 1
Service Tools
892/01077 Synchro Shuttle Gearbox - Selector
Shaft Lock Screw
A395350
Synchro Shuttle Gearbox - Setting ring socket spanners
A396590
A396600
892/01078 Synchro Shuttle Gearbox - Mainshaft
Adjuster
A396510
892/01079
(Mainshaft setting ring)
892/01080
(Layshaft setting ring)
