FX-1/FX-1R Maintenance Manual
Table 13-3-1-2.
DC Pow
er Supply
Unit <Parts List>
No.
Parts No. Name Qty. Remarks
1 L870E621000 Electromagnetic contactor 04 2 MC1 (For XL), MC2 (For XR)
2 L872E721000 Electromagnetic contactor 03 3
MC 3(For YL), MC4 (For YR),
MC5 (For YA)
3 L870E821000 Circuit protector 20A, 3P 2
CP1 (For XL), CP2 (For XR)
4 L870E721000 Circuit protector 15A, 3P 3
CP3 (For YL), CP4 (For YR),
CP5 (For YA)
5 L871E221000 Circuit protector 40A, 3P 1
CP6 (For Zθ)
6 HA00524000C Circuit protector 10A 3
CP7 (For 115L), CP8 (For 100L),
CP14 (For PS7)
7 L872E521000 Circuit protector 10A, 1A 2
CP9 (For PS1), CP18 (For PS9)
8 L871E321000 Circuit protector 12A 2
CP10 (For PS2), CP15 (For PS8)
9 HA005240000 Circuit protector 3A 1
CP11 (For PS3)
10 HA00524000B Circuit protector 8A 1
CP12 (For PS4)
11 L871E421000 Circuit protector 4A 1
CP13 (For PS5)
12 L871E121000 Circuit protector 30A, 1P 1
CP16 (For PS6)
13 L871E021000 Circuit protector 20A, 1P 1
CP17 (For Zθ, 48V)
14 KX000000150 Board type power supply (6V, 75W) 3
PS1, PS8, PS9
15 HX00543000A Board type power supply (24V, 300W) 1
PS2
16 HX004790000 Board type power supply (24V, 75W) 1
PS3
17 HX005420000 Board type power supply (12V, 100W) 1
PS4
18 HX00494000B Board type power supply (12V, 50W) 1
PS5
19 HX005770000 Board type power supply (5V, 150W) 1
PS6
20 HX00494000A Board type power supply (3V, 50W) 1
PS7
21 HB001280000 Power relay, DC24V 3
RL1, RL2, RL3
22 HB001280000 Power relay, DC24V 1
RL4
23 HB00110000A Power relay, AC100V 1
RL5
24 HA005290000 Seesaw switch 1
25 HM00033000A AC fan 1
26 40007364 POWER board assembly 1
27 40007366
Zθ-POWER board assembly
1
28 40000477 PSU slide bar 2
13-5
Rev. 2.00
To Next Page
