FX-1/FX-1R Maintenance Manual
{ Rear reference
前頁
①
③
④
Motor cable
To the top o
f
the trans
p
ort
Sensor cable
Motor cable
Run the cables to the top of the
transport unit together with the
YA-cable guide cables.
Sensor cable
Run the cables to the inside
of the chassis together with
the YA-cable guide cables.
Figure 14-4-2
 After the power has been turned ON, input an AWC offset of the MS parameters.
14-5
Rev. 2.00
