Table 23: Virtual Chassis Ports Connector Pinout Information (continued)
Pin NamePin Number
GNDB22
P2RXP0B23
P2RXN0B24
GNDB25
P2RXP1B26
P2RXN1B27
GNDB28
P2RXP2B29
P2RXN2B30
GNDB31
P2RXP3B32
P2RXN3B33
GNDB34
Related Topics â–  Virtual Chassis Cabling Configuration Examples on page 72
â–  Planning the Virtual Chassis on page 58
â–  Understanding Virtual Chassis Components
â–  Understanding Virtual Chassis Hardware Configuration on page 58
Field-Replaceable Units (FRUs)
â–  Field-Replaceable Units in EX-series Switches on page 99
Field-Replaceable Units in EX-series Switches
Field-replaceable units (FRUs) are components that you can replace at your site. The
field-replaceable units (FRUs) in EX-series switches are:
â–  Power supply
â–  Fan tray
â–  Uplink module
â–  SFP transceiver
â–  XFP transceiver
Field-Replaceable Units (FRUs) â–  45
