Connecting AC Power to an EX2200 Switch
The power supply in an EX2200 switch is located on the rear panel.
Ensure that you have the following parts and tools available:
•
A power cord appropriate for your geographical location
•
A power cord retainer clip
Ensure that you have connected the switch chassis to earth ground.
CAUTION: To meet safety and electromagnetic interference (EMI)
requirements and to ensure proper operation, youmust connectthe switches
to earth ground before you connect them to power. For installations that
require a separate grounding conductor to the chassis, use the protective
earthing terminal on the switch chassis to connect to the earth ground. For
instructions on connecting earth ground, see “Connecting Earth Ground to
an EX Series Switch” on page 103. An EX2200 switch gets additional grounding
when you plug the power supply in the switch into a grounded AC power
outlet by using the AC power cord appropriate for your geographical location
(see “AC Power Cord Specifications for EX2200 Switches” on page 66).
To connect AC power to the switch:
1. Squeeze the two sides of the power cord retainer clip and insert the L-shaped ends
of the wire clip into the holes in the bracket on each side of the AC power cord inlet
on the rear panel (Figure 47 on page 110).
The power cord retainer clip extends out of the chassis by 3 in.
2. Locate the power cord or cords shipped with the switch; the cords have plugs
appropriate for your geographical location. See “AC Power Cord Specifications for
EX2200 Switches” on page 66.
