The port uses an autosensing RJ-45 connector to support a 10/100Base-T connection.
Two LEDs on the port indicate link/activity on the port and the administrative status of
the port. See “Management Port LEDs in EX2200 Switches” on page 17.
Table 13 on page 25 provides the pinout information for the RJ-45 connector for the
management port. An RJ-45 cable, with a connector attached, is supplied with the switch.
Table 13: Management Port Connector Pinout Information for EX2200 Switches
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1-2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 2TRP2-6
Related
Documentation
See EX2200 Switches Hardware Overview on page 3 for port location.•
• Connecting an EX Series Switch to a NetworkforOut-of-Band Management on page 113
Optical Interface Support in EX2200 Switches
Uplink ports and dual-purpose uplink ports on the front panel in EX2200 switches support
SFP transceivers. This topic describes the optical interfaces supported for those
transceivers. It also lists the copper interface supported for the SFP transceivers.
NOTE: Use only optical transceivers and optical connectors purchased from
Juniper Networks for your EX Series switches.
The two tables in this topic describe the optical interface support over single-mode
fiber-optic (SMF) and multimode fiber-optic (MMF) cablesand over the copper interface
for SFP transceivers:
•
Table 14 on page 26—Optical interface support and copper interface support for Gigabit
Ethernet SFP transceivers in EX2200 switches except EX2200-C switches.
•
Table 15 on page 37—Optical interface support for Fast Ethernet SFP transceivers
except EX2200-C switches.
•
Table 16 on page 43—Optical interface support and copper interface support for SFP
Transceivers in EX2200-C switches.
25Copyright © 2011, Juniper Networks, Inc.
Chapter 3: Component Specifications
