Mini-USB Port Specifications for an EX2200 Switch
The EX2200-C switch, the compact, fanless model, has two management console ports:
an RJ-45 port, and a Mini-USB Type-B port.
By default, the RJ-45 port is set as the active console port. It can display all the early boot
and low-level message output and you can access the switch through this port in the
debugger prompt. The Mini-USB Type-B port is the passive console port. You can change
the status of the port to active or passive using the port-type configuration statement.
See Configuring the Console Port Type (CLI Procedure).).
The Mini-USB Type-B console port uses a Mini-B plug (5-pin) connector to connect to
a console management device. The default baud rate for the console port is 9600 baud.
Table 10 on page 22 provides the pinout information of the Mini-USB Type-B console
port.
Table 10: Mini-USB Type-B Console Port Pinout Information for EX2200-C Switches
DescriptionSignalPin
+5 VDCVCC1
Data -D-2
Data +D+3
May be N/C, GND or used as an attached device presence indicatorN/CX
GroundGND4
