Juniper EX2200 Series User Manual

• Mounting an EX2200 Switch on page 74
• Installing and Connecting an EX2200 Switch on page 71
EX2200 Switch Hardware and CLI Terminology Mapping
This topic describes the hardware terms used in EX2200 switch documentation and the
corresponding terms used in the Junos OS command line interface (CLI). See Table 3 on
page 10.
Table 3: CLI Equivalents of Terms Used in Documentation for EX2200 Switches
Additional
Information
Item in
Documentation
Value (as displayed
in the CLI)
Description (as
displayed in the CLI)
Hardware Item (as
displayed in the CLI)
“Chassis Physical
Specifications for
EX2200 Switches” on
page 9
Switch chassis–One of the following:
•
EX2200-C-12T-2G
•
EX2200-C-12P-2G
•
EX2200-24T-4G
•
EX2200-24P-4G
•
EX2200-24T-4G-DC
•
EX2200-48T-4G
•
EX2200-48P-4G
Chassis
Understanding
Interface Naming
Conventions on EX
Series Switches
The switch does not
have actual FPCs. In
this case, FPC refers to
the switch itself.
Value of n is always 0.Abbreviated name of
the Flexible PIC
Concentrator (FPC)
One of the following:
•
EX2200-C-12T-2G
•
EX2200-C-12P-2G
•
EX2200-24T-4G
•
EX2200-24P-4G
•
EX2200-24T-4G-DC
•
EX2200-48T-4G
•
EX2200-48P-4G
FPC (n)
Understanding
Interface Naming
Conventions on EX
Series Switches
The switch does not
have actual PIC
devices; see entries for
PIC 0 through PIC 1 for
the equivalent item on
the switch.
n is a value in the range
of 0-1.
Abbreviated name of
the Physical Interface
Card (PIC)
PIC (n)
Copyright © 2011, Juniper Networks, Inc.10
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Series Specifications

General

Brand	Juniper
Model	EX2200 Series
Category	Network Router
Language	English
