Table 54: EX2300 Switch Mounting Methods (continued)
More InformationSwitch ModelMounting Method
On two posts in a 19-in. rack-mounting brackets or cabinet by using
the separately orderable two-post rack-mounting brackets
EX2300-CFour-post rack or cabinet
On four posts in a 19-in. rack-mounting brackets or cabinet by using
the separately orderable four-post rack-mount kit
EX2300
In a position recessed 2 in. from the front of a 19-in. rack or cabinet
by using the 2-in.-recess front-mounting brackets in the separately
orderable four-post rack-mount kit. You can mount the switch in this
recessed position on two-post or four-post racks and cabinets.
EX2300Recessed position
The holes in the mounting brackets are placed 1 U (1.75 in. or 4.45 cm) apart so that the
switch can be mounted in any rack or cabinet that provides holes spaced at that distance.
Related
Documentation
Mounting an EX2300 Switch on a Desk or Other Level Surface on page 129•
• Mounting an EX2300-C Switch Under a Desk or Other Level Surface by Using Screws
on page 131
• Mounting an EX2300 Switch on a Wall on page 141
• Mounting an EX2300-C Switch on or Under a Surface Made of Ferrous Material on
page 149
• Mounting an EX2300 Switch on Two Posts of a Rack or Cabinet on page 135
• Mounting an EX2300 Switch on Four Posts of a Rack or Cabinet on page 137
• Mounting an EX2300 Switch in a Recessed Position in a Rack or Cabinet on page 153
• Connecting Earth Ground to an EX Series Switch on page 155
Mounting an EX2300 Switch on a Desk or Other Level Surface
You can mount an EX2300 switch on a desk or other level surface byusing the four rubber
feet that are preinstalled on the switch. The rubber feet stabilize the chassis.
Before mounting the switch on a desk or other level surface:
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX2300 Switches” on page 51.
•
Place the desk in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
•
Read “General Safety Guidelines and Warnings” on page 223, with particular attention
to “Chassis Lifting Guidelines” on page 232.
