Juniper EX2300-C Hardware Guide

You must provide the serial number to the Juniper Networks Technical Assistance Center
(JTAC) when you contact them to obtain a Return Material Authorization (RMA) number.
If the switch is operational and you can access the CLI, you can list serial numbers for
the switch and for some components with a CLI command. If you do not have access to
the CLI or if the serial number does not appear in the command output, you can locate
the serial number ID label on the physical switch (see Figure 74 on page 205) or component.
NOTE: Ifyouwant to find the serial number onthe physicalswitchcomponent,
you need to remove the component from the switch chassis, for which you
must have the required parts and tools available.
•
Listing the Switch and Components Details with the CLI on page 204
•
Locating the Chassis Serial Number ID Label on an EX2300 Switch on page 205
Listing the Switch and Components Details with the CLI
To list the switch and switch components and their serial numbers, enter the following
CLI command:
user@switch> show chassis hardware
The following are sample output of this command on EX2300-C and EX2300 switches:
Hardware inventory:
Item Version Part number Serial number Description
Chassis HV0215410003 EX2300-C-12P
Pseudo CB 0
Routing Engine 0 BUILTIN BUILTIN RE-EX2300C-12P
FPC 0 REV 04 650-059984 HV0215410003 EX2300-C-12P
CPU BUILTIN BUILTIN FPC CPU
PIC 0 REV 04 BUILTIN BUILTIN 12x10/100/1000 Base-T
PIC 1 REV 04 650-059984 HV0215410003 2x10G SFP/SFP+
Xcvr 0 REV 01 740-021309 T09K00695 SFP+-10G-LR
Xcvr 1 REV 01 740-030658 AD1146A05JT SFP+-10G-USR
Power Supply 0 JPSU-170W-AC
Hardware inventory:
Item Version Part number Serial number Description
Chassis JY0215410033 EX2300-24P
Pseudo CB 0
Routing Engine 0 BUILTIN BUILTIN RE-EX2300-24P
FPC 0 REV 05 650-059968 JY0215410033 EX2300-24P
CPU BUILTIN BUILTIN FPC CPU
PIC 0 REV 05 BUILTIN BUILTIN 24x10/100/1000 Base-T
PIC 1 REV 05 650-059968 JY0215410033 4x10G SFP/SFP+
Xcvr 0 REV 01 740-030658 AD1125A03ES SFP+-10G-USR
Xcvr 1 REV 01 740-021308 AJP0TDZ SFP+-10G-SR
Xcvr 3 REV 01 740-021309 A9401FL SFP+-10G-LR
Power Supply 0 JPSU-450W-AC-AFO
Fan Tray 0 Fan Module, Airflow Out
(AFO)
Fan Tray 1 Fan Module, Airflow Out
(AFO)
Copyright © 2017, Juniper Networks, Inc.204
EX2300-C and EX2300 Switches Hardware Guide

Juniper EX2300-C Specifications

General

Safety	UL-UL60950-1, C-UL CAN/CSA 22.2 No.60950-1, TUV/GS EN 60950-1, CB-IEC60950-1, EN 60825-1
Form factor	1U
Product color	Black
Rack mounting	Yes
Electromagnetic compatibility	FCC 47CFR 15 A, EN 55022 A, ICES-003 A, VCCI A, AS/NZS CISPR 22 A, EN 55024, EN 300386, CE
Console port	USB
SFP+ module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	12
Number of VLANs	4093
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z
Virtual LAN features	Tagged VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Power consumption (max)	20 W
Memory type	DRAM
Noise level	0 dB
Flash memory	2000 MB
Processor frequency	1250 MHz
Virtual stacking (units)	4
Operating altitude	0 - 1524 m
Non-operating altitude	1524 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Throughput	47 Mpps
Jumbo frames	9216
MAC address table	16000 entries
DHCP features	DHCP server, DHCP client
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP, SSH-2
Fiber ethernet cabling technology	1000BASE-X
Switch type	Managed
Switch layer	L2/L3

Weight and Dimensions

Depth	239 mm
Width	279 mm
Height	44 mm
Weight	2480 g
