Juniper EX2300-C Hardware Guide

Table 31: Site Electrical Wiring Guidelines (continued)
GuidelinesSite Wiring Factor
To reduce or eliminate RFI from your site wiring, do the following:
•
Use a twisted-paircablewith a good distribution of grounding
conductors.
•
If you must exceed the recommended distances, use a
high-quality twisted-pair cable with one ground conductor
for each data signal when applicable.
Radio frequency interference
If your site is susceptible to problems with electromagnetic
compatibility (EMC), particularly from lightning or radio
transmitters, seek expert advice.
Some of the problems caused by strong sources of
electromagnetic interference (EMI) are:
•
Destruction of the signal drivers and receivers in the device
•
Electrical hazards as a result of power surges conducted over
the lines into the equipment
Electromagnetic compatibility
Related
Documentation
General Safety Guidelines and Warnings on page 223•
• General Electrical Safety Guidelines and Warnings on page 251
• Prevention of Electrostatic Discharge Damage on page 253
Chassis Physical Specifications for EX2300 Switches
The EX2300 switch chassis is a rigid sheet-metal structure that houses the hardware
components. Table 5 on page 15 summarizes the physical specifications of the EX2300
switch chassis.
Table 32: Physical Specifications of the EX2300 Switch Chassis
EX2300 ValueEX2300-C ValueDescription
1.75 in. (4.45 cm)1.72 in. (4.36 cm)Chassis height
•
17.4 in. (44.19 cm)
•
19 in. (48.26 cm) with mounting brackets
attached
•
10.98 in. (27.9 cm)
•
18.86 in. (47.9 cm) with mounting brackets
attached
Chassis width
•
Models without PoE capability: 10.2 in.
(25.9 cm)
•
Models with PoE capability: 12.2 in. (30.98 cm)
9.45 in. (23.8 cm)Chassis depth
•
EX2300-24T: 7.25 lb (3.29 kg)
•
EX2300-24P: 9.89 lb (4.49 kg)
•
EX2300-24T-DC: 7.83 lb (3.55 kg)
•
EX2300-48T: 8.28 lb (3.76 kg)
•
EX2300-48P: 11.06 lb (5.02 kg)
•
EX2300-C-12T: 5.45 lb (2.48 kg)
•
EX2300-C-12P: 6.99 lb (3.17 kg)
Weight
Copyright © 2017, Juniper Networks, Inc.58
EX2300-C and EX2300 Switches Hardware Guide

Juniper EX2300-C Specifications

General

Safety	UL-UL60950-1, C-UL CAN/CSA 22.2 No.60950-1, TUV/GS EN 60950-1, CB-IEC60950-1, EN 60825-1
Form factor	1U
Product color	Black
Rack mounting	Yes
Electromagnetic compatibility	FCC 47CFR 15 A, EN 55022 A, ICES-003 A, VCCI A, AS/NZS CISPR 22 A, EN 55024, EN 300386, CE
Console port	USB
SFP+ module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	12
Number of VLANs	4093
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z
Virtual LAN features	Tagged VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Power consumption (max)	20 W
Memory type	DRAM
Noise level	0 dB
Flash memory	2000 MB
Processor frequency	1250 MHz
Virtual stacking (units)	4
Operating altitude	0 - 1524 m
Non-operating altitude	1524 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Throughput	47 Mpps
Jumbo frames	9216
MAC address table	16000 entries
DHCP features	DHCP server, DHCP client
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP, SSH-2
Fiber ethernet cabling technology	1000BASE-X
Switch type	Managed
Switch layer	L2/L3

Weight and Dimensions

Depth	239 mm
Width	279 mm
Height	44 mm
Weight	2480 g
