Table 36: RJ-45 Management Port Connector Pinout Informaon (Connued)
Pin Signal Descripon
2 TRP1— Transmit/receive data pair 1
3 TRP2+ Transmit/receive data pair 2
4 TRP3+ Transmit/receive data pair 3
5 TRP3— Transmit/receive data pair 3
6 TRP2— Transmit/receive data pair 2
7 TRP4+ Transmit/receive data pair 4
8 TRP4— Transmit/receive data pair 4
Console Port Connector Pinouts for the QFX Series
The console port (labeled CON, or CONSOLE) is an RS-232 serial interface that uses an RJ-45 connector
to connect to a console management device. The default baud rate for the console port is 9600 baud.
Table 37 on page 86 provides the pinout informaon for the RJ-45 console connector. An RJ-45 cable
and RJ-45 to DB-9 adapter are supplied with the QFX Series device.
NOTE: If your laptop or PC does not have a DB-9 plug connector pin and you want to connect
your laptop or PC directly to a QFX Series device, use a combinaon of the RJ-45 cable and
RJ-45 to DB-9 adapter supplied with the device and a USB to DB-9 plug adapter. You must
provide the USB to DB-9 plug adapter.
85
