Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-180 3700AS-901-01 Rev. D/June 2018
Example
dmm.func = "temperature"
Makes "temperature" the active DMM function.
dmm.func = "dcvolts"
dcv_nplc = dmm.nplc
Check the NPLC setting for DC volts.
dmm.func = dmm.DC_VOLTS
dmm.nplc = 0.5
dmm.range = 10
dmm.func = "twowireohms"
dmm.nplc = 0.1
dmm.range = 100000
dmm.func = "dcvolts"
print(dmm.nplc)
print(dmm.range)
dmm.func = dmm.TWO_WIRE_OHMS
print(dmm.nplc)
print(dmm.range)
Example showing how the instrument retains values
for each function.
Output:
0.5
10
.1
100000
dmm.func = "dcvolts"
print(dmm.configure.query("active", "\n"))
Select DC volts for the DMM function, then query
the active settings to see how the DC volts function
is presently configured.
Example output:
function = dcvolts
nplc = 5.000000E-001
aperture = 8.333333E-003
range = 1.000000E+001
auto zero = 1
auto delay = 2
filter enable = 0
filter type = 1
filter count = 3
filter window = 5.300000E+000
rel enable = 0
rel level = 0.000000E+000
display digits = 6
dB reference = 1.000000E+000
input divider = 0
units = 0
line sync = 0
limit 1 enable = 0
limit 1 autoclear = 1
limit 1 low value = -1.000000E+000
limit 1 high value = 1.000000E+000
limit 2 enable = 0
limit 2 autoclear = 1
limit 2 low value = -2.000000E+000
limit 2 high value = 2.000000E+000
math enable = 0
math format = 2
math mxb mfactor = 1.000000E+000
math mxb bfactor = 0.000000E+000
math mxb units = X
math percent = 1.000000E+000
