Keithley 6514 User Manual

17-6 SCPI Reference Tables
Table 17-4
SENSe command summary
Command Description
Default
parameter Ref
SCPI
[:SENSe[1]]
:FUNCtion <name> Select function; ‘VOLTage[:DC]’,
‘CURRent[:DC]’, ‘RESistance’ or ‘CHARge’.
‘VOLT’ Secs 3,
4, 5
√
:FUNCtion? Query measurement function. √
:DATA Path to return instrument readings: Secs 3,
4, 5
√
[:LATest]? Return the last instrument reading. √
:VOLTage[:DC] Path to configure volts function: √
:NPLCycles <NRf> Set integration rate in line cycles (PLC); 0.01 to
10.
6 (60Hz)
5 (50Hz)
Sec 6 √
:NPLCycles? Query NPLC. √
:RANGe Configure measurement range: Sec 6 √
[:UPPer] <NRf> Select range; -210 to 210 (volts). 21 √
[:UPPer]? Query range value. √
:AUTO <b> Enable or disable autorange. (see Note) √
:ULIMit <NRf> Select autorange upper limit; -210 to 210
(volts).
210
:ULIMit? Query upper limit for autorange.
:LLIMit <NRf> Select autorange lower limit; -210 to 210
(volts).
2.1
:LLIMit? Query lower limit for autorange.
:AUTO? Query state of autorange. √
:GUARd <b> Enable or disable driven guard. OFF Sec 3
:GUARd? Query state of driven guard.
:XFEedback <b> Enable or disable external feedback. OFF Sec 11
:XFEedback? Query state of external feedback.
:CURRent[:DC] Path to configure amps function: √
:NPLCycles <NRf> Set integration rate in line cycles (PLC); 0.01 to
10.
6 (60Hz)
5 (50Hz)
Sec 6 √
:NPLCycles? Query NPLC. √
:RANGe Configure measurement range: Sec 6 √
[:UPPer] <NRf> Select range; -0.021 to 0.021 (amps). 2.1e-4 √
[:UPPer]? Query range value. √
:AUTO <b> Enable or disable autorange. (see Note) √
