Kohler KDW 1603 User Manual

3
B C
D
A
G
H
F
E
J
K
L
M
N
O
P
Q
R
S
T
U
Z
Y
W
X
V
C1 D1
B1
E1
A1
A 468 F 208 L 75 Q 215.7 V 70 A1 266
B 235 G 175 M 220 R 81 W 356.4 B1 87
C
233max H 147.5 N 240 S 348 X 191 C1 99.6
D 231.3 J 250.2 O 310 T 250 Y 283.3 D1 336
E 425.2 K 154.2 P 171 U 187.5 Z 164 E1 68
- 25 - - 25 -
KDW 1603
OVERALL DIMENSIONS
Technical information
Note :Dimensionsshowninmm
DIMENSIONS mm
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
