Electric system
Starting Motor 24V
IskratypeAZE459824V3kW
RHdirectionofrotation.
Spacer ange for starter motor
The24Vstartermotorrequirestheassemblingofthespacerange.
Characteristic curves for starting motor Iskra type AZE
4598 24V 3 kW
Thethicklineswereobtainedatatemperatureof+20°C;thethin
lineswere obtainedat a temperatureof -20°C. Batterytype 55
Ah300A.
U=MotorterminalvoltageinVolt
n=Motorspeedinrpm.
A=AbsorbedcurrentinAmpere
P=PowerinkW
M =TorqueinNm
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
