Kohler KDW 1603 User Manual

109
108
107
106
110
Rif.
A
44,000÷44,025
0,040÷0,085 0,16
B
43,940÷43,960
C 43,000÷43,025
D 42,940÷42,960
E 42,000÷42,025
F 41,940÷41,960
6
Rif.
A
43,000÷43,025
0,040÷0,085 0,16
B
42,940÷42,960
C 42,000÷42,025
D 41,940÷41,960
- 62 - - 62 -
Disassembly / Reassembly
Checking camshaft bushing internal diameter
Useaboregauge.
If the diameter size does not correspond to the given value
remove the bushings using the special tool (pic. 109 and 110)
andreplace.
Dimensions
(mm)
Clearance
(mm)
(A-B) (C-D) (E-F)
Worn limit
(mm)
(A-B) (C-D) (E-F)
Camshaft bushing replacement
ToolpartNo.7104-1460-021
Components:
1 Mandrel
2Centeringbushing
3 Bushingdiam.44mm
4Bushingdiam.43mm
5Bushingdiam.42mm
Important
Before driving in the bushing, position it in such a way that
the lubricating hole maiches with the hole in the crankcase.
Dimensions
(mm)
Clearance
(mm)
(A-B) (C-D)
Worn limit
(mm)
(A-B) (C-D)
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
Camshaft journals and bushings in model KDW 1603
Note: A andCvaluesrefertodriveninandboredbushings.
Camshaft journals and bushings in models KDW 2204-2204/T
