Components:
1
-Tank
2-Fuelfeedingpump
3-Fuellter
4-Fueldeliverytube
5 -Injectorpumpsoverowtube
6-Injectionpump
7 -High-pressuretubebetweenpumpandinjector
8 -Injector
9 -Injectorreturntube
10-Solenoidvalve
FUEL SYSTEM
FUEL SYSTEM
Danger – Attention
Toavoidexplosionsorreoutbreaks,donotsmokeorusenakedamesduringtheoperations.
Fuelvapoursarehighlytoxic.Onlycarryouttheoperationsoutdoorsorinawellventilatedplace.
Keepyourfacewellawayfromtheplugtopreventharmfulvapoursfrombeinginhaled.Disposeoffuelinthecorrectwayanddonot
litterasitishighlypolluting.
Whenrefuelling,itisadvisabletouseafunneltopreventfuelfromspillingout.Thefuelshouldalsobelteredtopreventdustordirt
fromenteringthetank.Usethesametypeofdieselfuelasusedincars.Useofothertypesoffuelcoulddamagetheengine.Do
notusedirtydieselfuelormixturesofdieselfuelandwatersincethiswouldcauseseriousenginefaults.
