Disassembly / Reassembly
Check clearance between main bearings and journals
Use "Perfect Circle Plastigage" A and position it with a few
dropsofoilatthecenterofthehalfbearing.
 Tightenboltsto120Nm.
Determineclearance bymeasuringthesqueezedportionofthe
plastigagewiththeindexedscalesupplied.
 For clearance between main journals, connecting rod big
endjournalsandthecorrespondingbearingsg79.
Important
When replacing bearings make sure that the lower half is
kept separate from the upper one.
