Disassembly / Reassembly
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
Center main bearings
Themainbearingcapsandthecrankcasehavereferenceholes
markedonthem(one,twoorthree).
Important
In the assembly stage make sure that the number of holes on
the bearings matches those on the crankcase and that they
are on the same side.
Main bearing caps timing side - ywheel side
When retting rear ywheel side main bearing cap 1, replace
therubbergaskets2consideringthatAandBshouldprotrude
0.5÷1.0mmfromthecrankase;cutanyexcessportion.
Followthesameprocedureforthetimingsidemainbearingcap.
Tointroducethesupportscompletewithsiliconerubberseals2
intothecrankcaseplacetwoplatesCandDmeasuring0.1mm
inthicknessbetweenthesurfaces.
 Tightenthescrewsto120Nm.
