TECHNICAL DATA 21
131
21.7.2 50 SX MINI
Fork article number 07.18.1U.01
Fork WP XACT 5035
Fork length 580 mm (22.83 in)
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 1.8 N/mm (10.3 lb/in)
Weight of rider (standard): 25 … 35 kg (55 …
77 lb.)
2.0 N/mm (11.4 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 2.2 N/mm (12.6 lb/in)
Spring length with preload spacer(s) 337.5 mm (13.287 in)
Fork oil per fork leg 230 ± 10 ml (7.78 ± 0.34 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 134)
21.8 Shock absorber
21.8.1 50 SX, FACTORY EDITION
Shock absorber article number 03.18.7U.02
Shock absorber WP XACT 5735
Low-speed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
High-speed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 3 mm (0.12 in)
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 25 N/mm (143 lb/in)
Weight of rider (standard): 25 … 35 kg (55 …
77 lb.)
30 N/mm (171 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 35 N/mm (200 lb/in)
Spring length 130 mm (5.12 in)
Gas pressure 10 bar (145 psi)
Static sag 12 mm (0.47 in)
Riding sag 80 mm (3.15 in)
Fitted length 275 mm (10.83 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 135)
