21 TECHNICAL DATA
132
21.8.2 50 SX MINI
Shock absorber article number 03.18.9T.01
Shock absorber WP XACT 5435
Rebound damping
Standard 12 clicks
Spring preload
Standard 5 mm (0.2 in)
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 65 N/mm (371 lb/in)
Weight of rider (standard): 25 … 35 kg (55 …
77 lb.)
75 N/mm (428 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 85 N/mm (485 lb/in)
Spring length 120 mm (4.72 in)
Gas pressure 10 bar (145 psi)
Static sag 10 mm (0.39 in)
Riding sag 65 mm (2.56 in)
Fitted length 245 mm (9.65 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 135)
21.9 Chassis tightening torques
Hose clip, carburetor (50 SX MINI) - 2.8 Nm (2.07 lbf ft)
Hose clip, carburetor (50 SX, FAC-
TORY EDITION)
- 2.8 Nm (2.07 lbf ft)
Screw, brake line holder EJOT PT K60x20-Z 2 Nm (1.5 lbf ft)
Stop button screw M3 0.4 Nm (0.3 lbf ft)
Spoke nipple M3.5 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, brake assembly M5 5 Nm (3.7 lbf ft)
Screw, brake line guide
(50 SX MINI)
M5 2 Nm (1.5 lbf ft)
Screw, brake linings M5 8 Nm (5.9 lbf ft)
Screw, throttle slide cover
(50 SX MINI)
M5 1.3 Nm (0.96 lbf ft)
Screws on main silencer (FAC-
TORY EDITION)
M5 9 Nm (6.6 lbf ft)
Loctite
®
243™
Nut, push rod ball joint on foot
brake cylinder
M6 10 Nm (7.4 lbf ft)
Nut, push rod, foot brake lever M6 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, chain sliding guard
(50 SX MINI)
M6 2 Nm (1.5 lbf ft)
Screw, fender M6 6 Nm (4.4 lbf ft)
