TECHNICAL DATA 23
147
Stud, exhaust flange M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Spark plug M10 11 Nm (8.1 lbf ft)
Oil pressure sensor M10x1 10 Nm (7.4 lbf ft)
Screw plug, bearing support M10x1 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw plug, cam lever axis M10x1 8 Nm (5.9 lbf ft)
Screw plug, oil hole, timing chain
shaft
M10x1 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, unlocking of timing chain
tensioner
M10x1 8 Nm (5.9 lbf ft)
Coolant temperature sensor M10x1.25 10 Nm (7.4 lbf ft)
Screw, cylinder head M10x1.25 Tightening sequence:
Observe tightening sequence.
1st stage
5 Nm (3.7 lbf ft)
2nd stage
15 Nm (11.1 lbf ft)
3rd stage
90°
4th stage
90°
Collar greased / thread oiled
Screw plug, cylinder head oil drain M12x1.5 15 Nm (11.1 lbf ft)
Screw, rotor M12x1.5 90 Nm (66.4 lbf ft)
Thread greased
Screw plug, water jacket M16x1.5 20 Nm (14.8 lbf ft)
Nut, engine sprocket M20x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, inner clutch hub M20x1.5 135 Nm (99.6 lbf ft)
Loctite
®
243™
Plug, oil screen M20x1.5 20 Nm (14.8 lbf ft)
Plug, timing chain tensioner M24x1.5 25 Nm (18.4 lbf ft)
Screw plug, alternator cover M24x1.5 8 Nm (5.9 lbf ft)
23.3 Capacities
23.3.1 Engine oil
Engine oil 2.8 l (3 qt.) Engine oil (SAE 10W/50)
( p. 156)
23.3.2 Coolant
Coolant 1.60 l (1.69 qt.) Coolant ( p. 156)
