KTM 790 ADVENTURE R 2022 User Manual

13 SERVICE WORK ON THE CHASSIS
92
Finishing work
– Install the battery cover. ( p. 90)
– Install the left side cover. ( p. 88)
– Mount the seat. ( p. 82)
13.20 Removing right fuel tank spoiler
Preparatory work
– Remove the seat. ( p. 82)
– Remove the right side cover. ( p. 88)
– Remove the battery cover. ( p. 89)
F02048-10
Main work
–
Remove screw
1
.
–
Remove screws
2
.
F02058-10
– Remove the fuel tank spoiler from the rubber bushing in
area
A
.
– Pull off the right fuel tank spoiler sideways and remove it
toward the front.
