7 COMBINATION INSTRUMENT
30
The oil pressure warning lamp lights up red – The oil pressure is too low. Stop immediately,
taking care not to endanger yourself or other road users in the process, and switch off the
engine.
The alarm system indicator lamp lights up or flashes red – Status or error message of the
alarm system.
The cruise control system indicator lamp (optional) lights up yellow – The cruise control sys-
tem function is switched on, but cruise control is not activated.
The cruise control system indicator lamp (optional) lights up green – The cruise control sys-
tem function is switched on and cruise control is activated.
The high beam indicator lamp lights up blue – The high beam is switched on.
The general warning lamp lights up yellow – A note/warning note on operating safety has been
detected. This is also shown in the display.
7.7 Display
F01769-10
1
Speed ( p. 32)
1
Shift warning light ( p. 32)
The shift warning light is integrated in the tachometer display.
2
Gear display
3
Unit for the speed display
4
Speedometer ( p. 32)
5
Unit for the speedometer
6
Cruise control indicator (optional) ( p. 33)
7
Ride display ( p. 33)
8
ABS display ( p. 33)
9
MTC display ( p. 33)
